VirtualBox MacOS

you can use oracle virtualbox on macos bigsur to install litmus edge before you begin prepare your environment for running virtualization by using oracle virtualbox review verified vm versions docid 36xpluiltp2qajsr8lthw and confirm the correct version to download see virtualbox downloads https //www virtualbox org/wiki/downloads refer to virtualbox documentation https //www virtualbox org/wiki/documentation to learn more the virtual machine will run on the same physical network card as the host environment to ensure that the device can communicate with data sources such as plc, dcs or cnc and can be accessed through the web ui, make sure that communication can be established adjust the system clock for the host environment prior to installing litmus edge utc is recommended the 15 day trial period may be rejected and invalidated by the license server if the system clock is not adjusted if this happens, contact your litmus representative obtain a valid file in the iso format (example filename \<litmusedge std 3 1 5 0 amd64> iso ) you can get the iso file from the litmus central portal https //central litmus io/ to use virtualbox on macos bigsur to install litmus edge, you will need to do the following step 1 create a virtual machine step 2 configure settings step 3 log in to litmus edge to jump to a specific section, refer to the table of contents on the right side and click the corresponding step step 1 create a virtual machine you will first need to create the virtual machine that will run litmus edge to create the virtual machine start the oracle virtualbox application click the new icon from the name and operating system dialog box, configure the following name enter a name for the virtual machine type select other version select other/unknown (64 bit) click continue the memory size dialog box appears from the memory size dialog box, enter 4096 in the mb field click continue the hard disk dialog box appears from the hard disk dialog box, select create a virtual hard disk now and click create the hard disk file type dialog box appears from the hard disk file type dialog box, select vdi ( virtualbox disk image ) and click continue the storage on physical hard disk dialog box appears from the storage on physical hard disk dialog box , select fixed size and click continue the file location and size dialog box appears from the file location and size dialog box, enter 32 00 in the size field and click create the progress bar appears, and then the hard disk dialog box appears from the hard disk dialog box, select create a virtual hard disk now and click create the virtualbox manager appears step 2 configure settings after installing the virtual machine, you will need to configure its settings to configure the settings from the open oracle virtualbox application, select the deployed virtual machine from the left pane click the settings icon, and then click the general section in the right pane the general dialog box appears from the general dialog box, select the system icon at the top the system dialog box appears from the system dialog box, configure the following enable i/o apic select the checkbox hardware clock in utc time select the checkbox processor click processor and enter 2 click storage the storage dialog box appears from the storage dialog box, select the empty device in the left pane hover over the optical drive icon and select choose a disk file navigate to the iso file, and then click open click network the network dialog box appears from the network dialog box, select bridged adapter from the attached to drop down list and the appropriate network card name click ok the virtualbox manager appears from the virtualbox manager , click start the terminal user interface (tui) opens and runs the installation you configured, and then the virtualbox manager appears click settings , and then click system from the system dialog box, configure the following optical uncheck the check box hard disk select hard disk and click the up arrow to move it up in the boot order enable efi (special oses only) select the check box click ok the virtualbox manager appears click start the vm starts up and the terminal window displays the urls to be used to access the edge device through the web ui if several urls are shown, use the first one after you create the virtual machine, you must configure the network adapters step 3 log in to litmus edge see access the litmus edge web ui docid\ tgtrj9deh1w ro24kmbmq for details on logging in see access the terminal user interface docid\ r1lz44wffv3h9jg33nwlp for instructions on how to navigate and log in for the first time troubleshooting if you don't see an option for a 64 bit version and only see a 32 bit version, refer to installation and deployments troubleshooting docid\ ihiewqeamznmwuo93hwyo
