Delete Model(s) from Digital Twin for one Litmus Edge

to delete model(s) with litmus excel add ins, you should be familiar with how models work in digital twins docid\ xlj3gvozyg 52ue4pb5u7 on litmus edge as well as the consequences before you begin you have installed the litmus excel add ins extension see install litmus excel add ins docid\ gzdhbj1xzznddthyocuuu for details you have prepared a prepare a new tool file to manage digital twin models docid\ ov8snxemrb3nvzjjk6duh model(s) have been add model(s) to digital twin for one litmus edge docid\ tjpszlsmmrlw pd 9j kd to digital twins initial preparation open a new dt model management tool file in excel if prompted, enable content to allow the code to run make sure the the tool is set connect to is set to one le delete models(s) import model(s) import the model settings for model(s) defined on litmus edge using the import model(s) wizard docid 6b2rmrjg50mf gtidwt8w users can set a filter to reduce the number of module(s) shown as selection to the user search option select what type of filter is to be used model name mask set the filter to be applied will be ignored if search option is set to all the wizard will show what filter will be applied press the search button to pull the filtered list of model(s) from litmus edge the user will be shown the filtered list of model(s) matching their filter select the model(s) to import and press the import button notes users can choose between press new search to set another filter and search again if the list doesn't show the model(s) the user wanted to import select all model(s) using the checkbox in the header row select a group of model(s) by selecting their respective check box select one model by selecting the respective check box select no model and close the wizard pressing the close button instead the selected model(s) with their settings are imported into the sheet once finished, the user can either p erform another search using the new search button finsih the import using the close button the action for each imported tag is set to m for modify mark model(s) for deleteion change the action to d for the models(s) you want to delete on litmus edge notes set the action to i for ignore for model (s) in the sheet you do not want to process executing actions if the tool also includes models with either the action a or m , it is recommended but not mandatory to verify the configuration first without executing the action by pressing the verify only button this will check that all required model settings are provided and logically correct and provide any finding to the user example below the user not select a uns connector despite having enabled uns in column uns enabled important the tool can not verify if all provided model settings are factually correct for example it can not verify that the value of a static attribute is correct for what the user want to achieve the model(s) can be deleted from litmus edge by pressing the verify + execute button this will check that all required model settings are provided and logically correct and provide any finding to the user if no issues have been identified, the tool will verify that the user wants to execute all the actions from the action column a add model(s) m modify model (s) d delete model (s) i ignore model (s) > do nothing to perform all actions, press the yes button the tool will perform all actions row by row when finished, a result summary is shown close the result summary by pressing the x close button the tool will ask if the user wants to re compare the model(s) against litmus edge to re compare, press the yes button to not re compare, press the no button if the user selected to press the yes button from aboves messagebox, the tool will pull all the model settings from litmus edge again including the modelid and also change the action to m for each model with a modelid or a formodel with no modelid troubleshooting as litmus edge doesn't allow to delete digital twin models which have digital instances associated with, the excel tool performs the same check for both verify only and verify + execute buttons from the litmusconfiguration ribbon in case a model has instances, the action will be changed from "d" to "i" and the user will be notified before the check after the check
